Output Channels:2 channels
Frequency Range:DC to 20 MHz
Amplitude Range:1 mVpp to 10 Vpp
Resolution:14 bits
Waveform Types:Sine, Square, Triangle, Pulse, Arbitrary
Sampling Rate:100 MSa/s
Phase Shift:+/- 10 degrees
Memory Depth:16 kpoints
Interface:USB, GPIB
The Tektronix 5440 Arbitrary Waveform Generator is designed to deliver precise and versatile signal generation for a wide range of applications. With a bandwidth of up to 100 MHz, it supports a variety of waveform types including arbitrary waveforms, sine waves, square waves, ramps, pulses, noise, and DC signals. This makes it an invaluable tool for researchers, developers, and engineers working in electronics and telecommunications.
The device features two independent output channels, providing flexibility for dual-channel experiments and tests. Each channel supports a resolution of 14 bits, ensuring high accuracy in signal generation. The sampling rate of 250 MSa/s allows for detailed and fast waveform creation, making it suitable for demanding applications.
With a deep memory depth of 16 kPoints per channel, users can store and recall complex waveforms efficiently. The Tektronix 5440 also includes multiple interfaces including USB, GPIB, and Ethernet, facilitating easy integration into existing systems and networks.
The ergonomic design of the Tektronix 5440 ensures ease of use, with intuitive controls and a clear display for efficient operation. Its robust construction guarantees durability and reliability, even under continuous usage conditions. Additionally, the user-friendly software interface simplifies waveform creation and editing processes.
For those requiring comprehensive support and customization options, the Tektronix 5440 is backed by excellent customer service and technical assistance. Whether you’re a student, researcher, or professional engineer, this instrument delivers the performance and functionality needed to push the boundaries of innovation.
