Semikron SKD30/12A1 Power Module, High-Performance Solid State Relay, Control & Protection Solutions

In stock

The SEMIKRON SKD30/12A1 High-Power IGBT Module is designed for industrial applications where high efficiency and reliability are paramount. It offers robust performance and excellent thermal management capabilities.

Manufacturer:SEMIKRON

Model:SKD30/12A1

Module Type:High-Power IGBT Module

Rated Voltage:1200 V

Rated Current:30 A

Case Temperature Range:-50°C to +150°C

Mounting Type:Press-Fit

Pin Count:6

Configuration:3-Phase Bridge

Maximum Gate-Emitter Voltage:±20 V

Material:Copper and Aluminum

Dimensions:120 x 85 x 15 mm

This high-power IGBT module from SEMIKRON is built to deliver exceptional performance and durability under demanding industrial conditions.

The SEMIKRON SKD30/12A1 boasts a maximum collector-emitter voltage of 1200V and can handle continuous currents up to 30A, making it ideal for power-intensive applications.

Its robust screw mount design ensures secure installation and operation in challenging environments.

With a configuration of a 3 phase bridge and 12 pins, this module offers versatile connectivity options for various industrial setups.

Designed for longevity, the module includes a maximum gate-emitter voltage of ±20V, providing reliable switching characteristics and minimizing power losses.
