Resistor Type:Metal Film
Operating Temperature Range:-40°C to +85°C
Termination Resistance:100 Ω ± 5%
Current Rating:1 A
Voltage Rating:DC 50 V
Environmental Protection:IP20
Mounting Style:Panel Mount
Dimensions (WxHxD):14mm x 14mm x 8mm
Integrating advanced materials and engineering, the ABB 1485A-C2 Terminating Resistor offers superior performance and reliability in industrial automation networks. Its robust polyamide housing ensures durability under demanding environmental conditions, from freezing temperatures (-40°C) to high operational heat (+85°C), guaranteeing uninterrupted operation.
This resistor is meticulously designed to match the stringent requirements of DeviceNet protocols, providing seamless integration and enhanced signal integrity across industrial automation systems. Its 50 Ohm termination resistance ensures minimal signal loss, improving data transmission efficiency.
Featuring a terminal block connector style and panel mount design, the 1485A-C2 is easily adaptable to various industrial settings, facilitating quick and secure installation without compromising on space or functionality.
With its compact dimensions of 110 mm x 25 mm x 20 mm and lightweight at 0.05 kg, this resistor optimizes workspace utilization and reduces overall system weight, making it an ideal choice for both new installations and retrofit projects.
The ABB 1485A-C2 Terminating Resistor comes equipped with a 10 W power rating, providing ample capacity to handle varying power demands without overheating. This, combined with its wide operating frequency range up to 10 MHz, ensures reliable performance across a broad spectrum of industrial applications.
