NI PXI-7811R High-Density Reconfigurable FPGA Module

In stock

The NI PXI-7811R is a high-performance Field-Programmable Gate Array (FPGA) module designed for real-time data acquisition and processing in industrial automation systems. This module supports flexible programming and is ideal for applications requiring rapid signal processing and analysis.

SKU: 17139617

Manufacturer:National Instruments

Model Number:PXI-7811R

Series:FlexRIO

Interface Type:PXI Express

Input/Output Interfaces:Multiple high-speed interfaces including PCIe x4, Ethernet, USB 3.0

Memory:Up to 1 GB DDR3 SDRAM

FPGA Model:Xilinx Kintex-7

Clock Speed:Up to 300 MHz

Power Supply:12 V DC

Dimensions:5.9 inches (W) x 6.6 inches (H) x 1.2 inches (D)

Weight:0.5 lbs

Certifications:CE, RoHS compliant

    The NI PXI-7811R is a high-performance reconfigurable FPGA module designed for a wide range of applications including real-time signal processing, communications, and control systems. With its state-of-the-art Xilinx Virtex-5 SX95T FPGA, it provides unparalleled processing power, making it perfect for demanding industrial automation tasks.

    This module comes equipped with two 14-bit ADCs and two 16-bit DACs, supporting up to 100 MS/s sample rate, which ensures precise and rapid data acquisition and generation. The on-board 1GB DDR3 SDRAM allows for efficient data handling, while the compact 5-slot PXI form factor makes it easy to integrate into existing systems without requiring significant space.

    Designed for flexibility, the NI PXI-7811R supports PXI Express interface, providing high-bandwidth connectivity essential for real-time operations. Its robust design and reliable performance make it an indispensable tool for engineers and scientists looking to push the boundaries of what’s possible in their research and development projects.

    To get started with the NI PXI-7811R, simply connect it to your PXI chassis and use LabVIEW or other compatible software to configure its FPGA logic. Whether you’re developing a custom control system, prototyping a new communication standard, or performing complex signal processing tasks, this module will provide the flexibility and performance needed to achieve your goals.

NI PXI-7811R

NI PXI-7811R

NI PXI-7811R
