National Instruments PXIe-5665 Vector Signal Analyzer

In stock

The National Instruments PXIe-5665 is a high-performance RF vector signal analyzer designed for the most demanding applications in wireless communication testing, radar systems, and electronic warfare. It offers unparalleled accuracy and reliability in measuring complex RF signals.

Module Type:Vector Signal Analyzer

Frequency Range:2 Hz to 6 GHz

Resolution Bandwidth:1 Hz to 20 MHz

Analysis Bandwidth:80 MHz

Dynamic Range:+10 dBm to -165 dBm

Input Sensitivity:-135 dBm

Phase Noise:-110 dBc/Hz @ 10 kHz Offset

Sampling Rate:up to 200 MS/s

Memory Depth:1.5 GB

Interface:PXI Express

The NI PXIe-5665 RF Vector Signal Analyzer delivers exceptional performance in the measurement and analysis of RF signals. Its wide frequency range from 100 kHz to 6 GHz ensures it meets the needs of various applications including wireless communication testing and radar systems. With an instantaneous bandwidth of up to 25 MHz, it provides precise measurements for complex signal analysis.

This module features high dynamic range, enabling it to measure signals from +10 dBm down to -151 dBm, making it ideal for a broad spectrum of applications. The resolution bandwidth can be set from 1 Hz to 20 MHz, allowing for detailed signal analysis.

With a sampling rate of up to 100 MS/s and sweep speed capabilities up to 150 sweeps per second, the PXIe-5665 ensures rapid and accurate measurements. The phase noise at 10 kHz offset is as low as -110 dBc/Hz, ensuring excellent signal integrity and reliability.

Designed with ease-of-use in mind, the PXIe-5665 integrates seamlessly with National Instruments’ software ecosystem, allowing for flexible and powerful data analysis. Whether you’re conducting rigorous testing in a lab or deploying in the field, the PXIe-5665 stands out as a reliable and versatile tool.
