National Instruments’ NI AT-GPIB-TNT IEEE-488.2 Industrial Interface Module

Protocol Compatibility:IEEE-488.2, GPIB

Communication Speed:Up to 20 MHz

Data Transfer Rate:1 Mbit/s

Power Supply:12 VDC ±10%

Physical Interface:DB-25 connector

Operating Temperature Range:-10°C to +50°C

Relative Humidity Range:5% to 95% non-condensing

    The National Instruments’ NI AT-GPIB-TNT IEEE-488.2 is engineered to meet the stringent requirements of modern industrial environments. Its compact design and robust construction ensure reliability and longevity in demanding applications.

    With its high-speed communication capabilities, this module significantly enhances productivity by reducing data transfer times and improving system throughput. It’s compatible with a broad spectrum of instruments, making it a versatile addition to any test bench or production line.

    The IEEE-488.2 compliance ensures compatibility with a wide array of National Instruments and third-party equipment, facilitating seamless integration into existing systems. This not only streamlines setup but also future-proofs your investment.

    Built for efficiency, the module includes features like error detection and correction mechanisms, ensuring data integrity during transmission. Its compatibility with TTL/CMOS signals means it can interface with a variety of legacy and new systems.

    The NI AT-GPIB-TNT IEEE-488.2 comes with a comprehensive set of documentation and support resources, including tutorials and application notes, which guide users through installation, configuration, and troubleshooting, ensuring a smooth integration process.
