GE SR745-W2-P1-G1-HI-E-H, Industrial Transformer Management System

In stock

The GE SR745-W2-P1-G1-HI-E-H is an advanced control system designed for managing and protecting transformers, autotransformers, and reactors. With its enhanced 40-character display and expanded keypad, it simplifies manual entry of setpoints, making it an ideal solution for industrial applications.

Model Number:SR745-W2-P1-G1-HI-E-H

Order Number:DS215TCEAG1BZZ01A

Transformer Protection System:Yes

Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz

Display Type:40-character Enhanced LCD

Dimensions:9″H x 7 ⅛”D x 7″W

RTD Type:3-wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum

Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA

Maximum Continuous Voltage Output:273 V

The GE SR745-W2-P1-G1-HI-E-H is designed to efficiently manage and protect transformers, autotransformers, and reactors. Its enhanced 40-character display and expanded keypad provide ease of use for manual entry of setpoints.

The system includes a robust transformer protection mechanism that can be easily mounted on a standard 19-inch panel. It ensures that the door to the chassis can freely open and close without interfering with other components.

The front of the unit features several LEDs that provide real-time alerts about various statuses and errors, ensuring timely maintenance and operation.

With a control power range of 90 to 300 V DC and 70 to 265 V AC at 48 to 62 Hz, this system offers versatile compatibility with different power sources.

Equipped with two windings per phase and a variety of RTDs, this system provides precise temperature monitoring and control, ensuring optimal performance and longevity of your equipment.
