Manufacturer:General Electric
Model:IC3600QOXC3
Category:Turbine Control Systems
Compatibility:Mark I-II
Component Type:Over-Speed Sensor Card
Features:Transformer, Resistors, Metal Oxide Varistors (MOV), Transistors
The GE IC3600QOXC3 is an essential over speed sensor card designed specifically for the Speedtronic Mark I-II turbine control systems.
It plays a crucial role in monitoring the operational parameters of the turbine, ensuring that it runs within safe limits.
This card features a robust design with a large transformer near its center on the left side, which helps in stabilizing the power supply and reducing noise.
Equipped with multiple resistors in various color-coded bands, this card provides precise resistance values necessary for accurate readings.
Additionally, it houses at least two Metal Oxide Varistors (MOVs) located close to the board’s upper edge, which serve as surge protectors, safeguarding the system against voltage spikes.
Small transistors in both round silver and black half-circle shapes are strategically placed to facilitate smooth operation and enhance reliability.
