GE 745-W3-P5-G5-HI-R Transformer Protection System - Enhancing Power Transformer Safety and Performance

GE 745-W3-P5-G5-HI-R Transformer Protection System – Enhancing Power Transformer Safety and Performance

In stock

The GE 745-W3-P5-G5-HI-R is a robust and reliable transformer protection system designed for industrial applications. It offers advanced protection features including three windings per phase, restricted ground fault detection, and comprehensive monitoring capabilities to safeguard transformer assets.

Weight:10 lbs, 8 oz (4.8 kg)

Software Version:EnerVista 745 Setup

Operating Temperature:-40°C to +60°C

Chassis:745 SR Series

Input Voltage:60 to 120 V

Ground Fault Detection:Restricted Ground Fault

Current Input Windings:3 phase current input windings at 5A

Overload Withstand:1 second at 80 times rated current, continuous at 3 times rated current

Dimensions:9”H, 7 ⅛”D, 7”W

The GE 745-W3-P5-G5-HI-R is a highly advanced transformer protection system designed for the most demanding industrial environments.

Featuring three windings per phase, it ensures robust protection against overloads and faults.

Its sophisticated design allows for seamless integration with existing systems, eliminating the need for additional metering equipment and connections.

The system is equipped with a high-resolution 40-character LCD display, offering real-time monitoring and control capabilities.

The EnerVista 745 Setup software enhances its functionality, allowing for detailed analysis and reporting.

With its wide operating temperature range, this transformer management relay is suitable for use in extreme environmental conditions, making it an ideal choice for industrial applications requiring reliable performance.

GE 745-W3-P5-G5-HI-R
