Facts F4-16AD-2 Analog Voltage Input Module, Automation Solutions for Industry

In stock

The F4-16AD-2 is an essential component in the DirectLogic 405 series, enabling seamless integration with logic controllers and external I/O devices. This versatile analog voltage input module efficiently processes and converts voltage signals into digital data for enhanced automation systems.

Module Type:Analog Voltage Input Module

Compatibility:DirectLogic 405 Series Controllers

Channels:16 single-ended

Resolution:12-bit

Input Voltage Range:0-10VDC

Power Requirement:5VDC @ 80mA base power + 21.6-26.4VDC external power supply

Output:Voltage sourcing with a 10mA max output

    The F4-16AD-2 module is meticulously engineered for demanding industrial environments. Its sixteen channels enable seamless integration with various peripheral devices, facilitating real-time data acquisition and processing. Each channel supports a wide input range of 0-10V DC, ensuring compatibility with a broad spectrum of sensors and transmitters. With a high-resolution 12-bit converter, the module accurately translates analog voltage signals into digital format, offering superior precision and reliability.

    Designed for longevity and robust operation, the module operates efficiently within a specified power range, requiring minimal power consumption while delivering consistent performance. It includes two selectable output ranges (0-5V DC and 0-10V DC), allowing for flexible integration with different types of equipment and control systems. Additionally, the F4-16AD-2 supports voltage sourcing with a 10 mA maximum, making it ideal for applications requiring precise control over analog outputs.

    Installation is straightforward, with all channels terminating into a single common, simplifying wiring configurations and reducing the risk of connection errors. By adhering to the recommended installation guidelines, users can ensure optimal functionality and extend the lifespan of their investment.

FACTS F4-16AD-2
