Allen Bradley AB 1747-L541/C SLC 5/04 Processor – Series C

Processor Type:Modular

Model Number:1747-L541/C

Manufacturer:AllenBradley

Series:SLC 5/04

Memory:16 KB

Backup:Flash

Interface:RS-232 Ports

Communication Protocol:EtherNet

Mounting:Chassis

Output Type:Backplane: 1 MA at 5 VDC

Response Time (Typical Scan):0.9 MS/Kword

Bit Execution Time:0.37 MIC-SEC

I/O Scan Time:0.255 MS

Programming Device:RSLogix™ 5000 Software

Enclosure:Open Type

Display:Status LEDs

Length:145 MM

Width:35 MM

Height:142 MM

Temperature Range:0 – 60 DEG C

Environmental Conditions:5 – 95%

    The Allen Bradley AB 1747-L541/C SLC 5/04 Processor – Series C is an indispensable component for modern industrial automation systems, offering a robust platform for controlling and managing complex operations. With its modular design, this processor allows for easy integration and scalability to meet diverse industrial needs.

    Featuring 16 KB of memory, it ensures ample space for programming and storing user-defined functions. The inclusion of Flash backup guarantees critical data retention during power loss, ensuring system reliability even in challenging industrial environments.

    Equipped with RS-232 ports, it facilitates seamless communication with other devices, enhancing connectivity within the factory floor. The EtherNet interface further expands networking capabilities, enabling high-speed data exchange for real-time control and monitoring.

    Designed for efficient operation, the processor boasts a typical scan time of just 0.9 milliseconds per kiloword, making it highly responsive to changing conditions. Its bit execution speed of 0.37 microseconds ensures swift processing of instructions, while the I/O scan time of 0.255 milliseconds ensures prompt response to input/output changes.

    The open-type enclosure and status LEDs provide clear visual feedback on the operational status of the processor, allowing for quick diagnosis and troubleshooting without the need for complex tools or equipment.
