Module Type:Digital DC Output
Number of Channels:16
Input Voltage:24 Volts DC
Output Voltage Range:10-50 VDC
On-State Voltage Drop:1.2 V
Off-State Output Leakage:1 mA
Load Capacity:1 mA per channel
Current Rating:Backplane: 0.28 A, Continuous Current Per Output: 0.25 A @ 60°C
Continuous Current Per Module:4 A @ 60°C
Isolation Voltage:Communication Circuits: 500 VDC, Backplane: 1500 VAC
Enclosure Type:Open Type
Mounting:Chassis
Temperature Range:0-60°C
Environmental Conditions:5%-95% relative humidity non-condensing
The Allen Bradley 1746-OG16 is engineered for reliability and performance in demanding industrial environments. This digital output module provides seamless integration with Allen-Bradley’s SLC 500 series, enhancing operational efficiency.
With its robust design, the 1746-OG16 ensures precise control over outputs, making it ideal for applications requiring accurate signal transmission and power management.
Featuring a compact form factor, this module is easy to integrate into existing control systems without compromising on functionality or performance. It supports a wide range of voltage levels, providing versatility in various industrial settings.
The module boasts high isolation levels, ensuring reliable communication circuits and backplane connections. Its temperature rating guarantees consistent operation within industrial conditions, from cold workshops to hot manufacturing floors.
Designed with an open type enclosure, the 1746-OG16 allows for flexible mounting options, catering to diverse installation requirements. This feature, combined with its low power consumption and efficient heat dissipation, makes it suitable for long-term operation in confined spaces.
