Model Type:SLC500
Manufacturer:Allen Bradley
Number Of Channels:4
Input Voltage Range:-20 To 20 V
Absolute Input Voltage:Plus/Minus 7.5 VDC Or 7.5 VAC RMS
Input Current Range:-30 To 30 MA
Voltage Rating:Overvoltage Protection: 7.5 VAC RMS
Input Range:-10 To 10 VDC – 1 LSB
Current Rating:Backplane Current Draw: 35 MA At 5 V, 85 MA At 24 V
Isolation:Backplane: 500 VDC, Enclosure: Open Type
The AB 1746-NIO4 module is engineered with precision for high-resolution signal acquisition, ensuring reliable data capture from various industrial sensors.
It supports common mode voltage ranging from -20 to 20 volts, providing a wide dynamic range suitable for diverse industrial applications.
Featuring a maximum absolute input voltage of Plus/Minus 7.5 volts DC or AC RMS, it ensures robust performance under varying electrical conditions.
The module offers an input range of -20 to 20 milliamps (MA), making it versatile for measuring current signals from different types of sensors.
With overvoltage protection at 7.5 volts AC RMS, the 1746-NIO4 safeguards against transient spikes and ensures continuous operation.
Equipped with backplane current draw capabilities at 35 milliamps at 5 volts and 85 milliamps at 24 volts, it efficiently manages power consumption for optimal system performance.
