Allen Bradley 1746-HT – High-Temperature Analog Input Module, Precision for Industrial Control Systems

Operating Voltage:12-24 VDC

Output Current:0-20 mA, 4-20 mA

Supply Current:Max. 125 mA @ 12 VDC

Load Compatibility:Up to 500 Ohms

Signal Types Supported:Analog Output

Communication Interface:Modbus RTU

Temperature Range:-20°C to +60°C

Humidity Range:5% to 95% non-condensing

    The AB 1746-HT is specifically engineered for industrial settings where temperature extremes pose a challenge to standard control equipment. With its wide operating temperature range from -40°C to +85°C, it ensures reliable operation in even the most demanding environments.

    Efficient power consumption of ≤ 1 W minimizes energy usage and heat generation, reducing the risk of overheating in enclosed spaces. This makes it an ideal choice for installations where cooling systems may not be readily available or efficient.

    Featuring versatile input voltage compatibility of 12 VDC to 24 VDC, the module offers flexibility in various industrial applications without the need for extensive voltage conversion equipment.

    Supporting Modbus RTU protocol, the 1746-HT facilitates seamless integration with existing industrial automation systems, enabling data exchange and remote monitoring capabilities.

    Equipped with 16 Inputs and 16 Outputs, the module provides ample connectivity for complex control tasks, accommodating a wide range of sensors and actuators in manufacturing processes, HVAC systems, and other industrial applications.
