Operating Voltage:12 V DC
Operating Frequency:50 kHz
Protocol Support:Modbus TCP/IP, Ethernet/IP
Data Transfer Rate:10/100 Mbps
Environmental Conditions:-20°C to +60°C, IP20 Protection
Dimensions (DxWxH):51.8 x 175.26 x 35.56 mm
Weight:0.6 kg
Connector Type:M12 x 0.75
Certifications:CE, UL, CSA, IECEx
The ABB TB523-2ETH Terminal Base is engineered with precision to ensure durability and longevity in harsh industrial conditions. Its compact design allows for easy integration into existing systems without compromising on functionality or performance.
Featuring a high current capacity of up to 240 Amps, this terminal base is capable of handling even the most demanding power distribution requirements. It’s equipped with 24 connection points, providing ample space for multiple wire connections.
With an insulation level of IP54, it effectively safeguards against dust and light water ingress, ensuring reliable operation in a variety of industrial settings. The terminal base operates within a wide temperature range from -25°C to +60°C, making it suitable for a broad spectrum of environmental conditions.
Equipped with a robust connection type, the ABB TB523-2ETH Terminal Base ensures secure and stable connections, crucial for maintaining system reliability and safety. Its compatibility with voltages up to 600V AC/DC further enhances its versatility across different applications.
Designed with user-friendliness in mind, the terminal base features intuitive labeling and color coding, facilitating quick and error-free wiring. It’s compatible with a wide range of ABB and industry-standard terminal blocks, ensuring seamless integration with existing infrastructure.
