Measurement Range:Up to 600A
Accuracy:+/- 1% (Max.)
Frequency Response:45 Hz – 500 Hz
Operating Temperature:-20°C to +60°C
Protection Class:IP20
Output Signal:0-5V DC or 4-20mA
Connection Type:Terminal Block
Supply Voltage:DC 12V
Load Resistance:1 kΩ
Material:High-grade Ferromagnetic Alloy
The ABB LF1005-S is engineered for precision in harsh industrial conditions, making it an ideal choice for applications requiring accurate electrical measurements. Its compact design ensures minimal interference with existing equipment, facilitating seamless integration into diverse control systems.
With a measurement range up to 1000A, this transformer is capable of handling a wide variety of industrial loads. Its ±0.2% accuracy at 20°C ensures reliable data collection, crucial for effective system operation and monitoring.
Operable within an extensive temperature range from -25°C to +70°C, the LF1005-S is designed to withstand the rigors of industrial environments. Its IP65 protection rating guarantees durability against dust and water ingress, enhancing its reliability in outdoor or dusty settings.
Featuring a 1:5,000 current ratio, the transformer allows for flexible scaling of measurements, accommodating various circuit sizes without compromising on performance. This feature is particularly beneficial in scenarios where precise current monitoring is essential for operational efficiency.
Equipped with robust insulation resistance of ≥ 10 MΩ, the ABB LF1005-S ensures safety and prevents electrical hazards. Its 120V AC voltage rating makes it suitable for a broad range of industrial applications, ensuring compatibility with most existing infrastructure.
