Operating Voltage:24V DC
Rated Current:10A
Protection Class:IP20
Operating Temperature Range:-25°C to +60°C
Relay Type:Solid State
Switching Capacity:Up to 250V AC/3A
Mounting Method:Panel Mount
Input Delay Time:Adjustable, typically 0.1s to 1s
Response Time:Less than 1ms
Protection Characteristics:Thermal overload, short-circuit, and phase loss
Integrating cutting-edge technology, the ABB 193-EC2DD Solid State Overload Relay offers unparalleled motor protection against overloads, short-circuits, and other electrical faults. This module is designed to seamlessly integrate into various industrial control systems, enhancing system reliability and efficiency.
Featuring a compact and durable design, the relay utilizes solid-state switching elements for superior performance and longer life compared to traditional mechanical relays. Its advanced algorithm ensures precise detection and response to motor overload conditions, preventing damage and downtime.
With a wide operating voltage range of 24V DC, this relay is compatible with a variety of industrial applications. It supports a current rating of up to 16A, making it suitable for a broad spectrum of motors and equipment. The 4 Form C (4C) relay contacts provide multiple connection options for diverse circuit configurations.
Operable within an extensive temperature range of -25°C to +60°C, the ABB 193-EC2DD is designed for robust performance in harsh industrial environments. It is equipped with a life expectancy exceeding 1 million operations, ensuring a long service life and reduced maintenance requirements.
For ease of integration and operation, the relay offers simple wiring and configuration options, adhering to international safety standards. It is part of ABB‘s comprehensive range of motor protection solutions, providing customers with a reliable choice for their industrial automation needs.
